| Art No. | WLL | Sheave Dia | Hook | Eye | Wire Rope | Weight | ||
| Ton | D mm | A1 mm | A2 mm | B mm | C2 mm | mm | kg/pc | |
| BL03-075 | 1.00 | 75.00 | 268.00 | 227.00 | 87.00 | 77.00 | 8.00 | 2.80 |
| BL03-100 | 1.00 | 100.00 | 311.50 | 284.50 | 112.00 | 88.00 | 10.00 | 4.30 |
| BL03-125 | 2.00 | 125.00 | 370.00 | 344.00 | 140.00 | 100.00 | 13.00 | 7.80 |
| BL03-150 | 2.00 | 150.00 | 442.50 | 417.00 | 168.00 | 146.00 | 16.00 | 12.20 |
| BL03-180 | 3.00 | 180.00 | 498.00 | 478.00 | 204.00 | 157.00 | 19.00 | 18.50 |
| BL03-200 | 4.00 | 200.00 | 590.50 | 556.00 | 226.00 | 188.00 | 22.00 | 31.00 |
| BL03-250 | 5.00 | 250.00 | 706.50 | 651.00 | 276.00 | 220.00 | 25.00 | 49.80 |
| BL03-300 | 6.00 | 300.00 | 795.00 | 775.00 | 330.00 | 238.00 | 26.00 | 72.00 |
| BL03-350 | 10.00 | 350.00 | 934.00 | 898.00 | 395.00 | 260.00 | 28.00 | 102.00 |
