| Art No. | Nominal Diameter | Nominal Tensile Strength | Approx. Weight | ||||
| 1570N/mm2 | 1770N/mm2 | ||||||
| Minimum Breaking Strength (KN) | kg/m | ||||||
| mm | FC | WRC | FC | WRC | FC | WRC | |
| WP15-04 | 4 | - | - | 9.0 | 9.3 | 0.0612 | 0.0643 |
| WP15-05 | 5 | - | - | 14.1 | 14.5 | 0.0957 | 0.1000 |
| WP15-06 | 6 | - | - | 20.3 | 20.9 | 0.1380 | 0.1450 |
| WP15-07 | 7 | - | - | 27.6 | 28.5 | 0.1880 | 0.1970 |
| WP15-08 | 8 | 32.0 | 33.0 | 36.1 | 37.2 | 0.2450 | 0.2570 |
| WP15-09 | 9 | 40.5 | 41.7 | 45.7 | 47.0 | 0.3100 | 0.3260 |
| WP15-10 | 10 | 50.0 | 51.5 | 56.4 | 58.1 | 0.3830 | 0.4020 |
| WP15-11 | 11 | 60.5 | 62.3 | 68.2 | 70.3 | 0.4630 | 0.4860 |
| WP15-12 | 12 | 72.0 | 74.2 | 81.2 | 83.6 | 0.5510 | 0.5790 |
| WP15-13 | 13 | 84.5 | 87.1 | 95.3 | 98.1 | 0.6470 | 0.6790 |
| WP15-14 | 14 | 98.0 | 101.0 | 111.0 | 114.0 | 0.7500 | 0.7880 |
| WP15-16 | 16 | 128.0 | 132.0 | 144.0 | 149.0 | 0.9800 | 1.0300 |
| WP15-18 | 18 | 162.0 | 167.0 | 183.0 | 188.0 | 1.2400 | 1.0300 |
| WP15-20 | 20 | 200.0 | 206.0 | 2269.0 | 232.0 | 1.5300 | 1.6100 |
| WP15-22 | 22 | 242.0 | 249.0 | 273.0 | 281.0 | 1.8500 | 1.9500 |
| WP15-24 | 24 | 288.0 | 297.0 | 325.0 | 335.0 | 2.2000 | 2.3100 |
| WP15-26 | 26 | 338.0 | 348.0 | 381.0 | 393.0 | 2.5900 | 2.7200 |
| WP15-28 | 28 | 392.0 | 404.0 | 442.0 | 455.0 | 3.0000 | 3.1500 |
